Certification : EMC FCC Part 15 Class B, ICES 003 Class B,\nIEC 60601-1-2 RoHS 2002/95/EEC
Housing material : Plastic
International Protection (IP) code : IP54
LED indicators : Charging, Power
Product colour : Black
Operating relative humidity (H-H) : 5 - 85 %
Operating temperature (T-T) : 0 - 50 °C
Storage temperature (T-T) : -40 - 70 °C
Other features : Dimensions (WxDxH) 70 x 186 x 98 mm
Light source : LED
Cables included : RS-232
International Protection (IP) code : IP54
Ports & interfaces : Bluetooth
Cable length : 1,8 m
Standard interfaces : RS-232, RS-485, USB, Keyboard wedge
Battery technology : Lithium Polymer (LiPo)
Scanning : Light levels (direct sunlight) : 0 - 108 lx
Maximum range : 6 m
Maximum scan width : 10 cm
Pitch reading angle : 0 - 65 °
Read rate (max) : 547 reads/s
Tilt angle range : 0 - 35 °
Tilt reading angle : 0 - 45 °
Wavelength : 612 nm
Yaw reading angle : 0 - 65 °
Harmonized System (HS) code : 84716070
På lager | Ja |
Titel | Type | Størrelse | Download |
---|---|---|---|
LI4278-TRBU0100ZER.pdf | 260.98KB | Download |
